Product Specification

Information on the sizes, weights, manufacturing and finishes of our products.

Core

Perform Panel products are manufactured using either a 5-layer plywood core or a moisture resistant mdf. The boards are bonded to HPL (high pressure laminate) to the front face and a backing HPL to reverse. Suitable for wet rooms, showers and areas with extremely high humidity.

Where the long edges of the panels are supplied with the Nu-lock tongue and groove click system, certified 7-layer birch plywood is used as the core substrate.

High Pressure Laminate

Paper forms the basis of high pressure laminates. The paper is impregnated with phenolic and melamine resins, dried and compressed to form a hard wearing, stable coating. The laminate can be bonded to various substances and is resistant to most chemicals.

Finishes

Perform panel is available in a selection of different finishes, depending on the selected decor. These include gloss, matt
and textured finishes.

Perform panel is supplied in an 11mm thickness, with three standard sizes, in either a moisture resistant MDF or a WBP plywood core.

2400 x 600mm

Plywood Weight
12kg
Moisture Resistant MDF Weight
13kg

2400 x 900mm

Plywood Weight
18kg
Moisture Resistant MDF Weight
20kg

2400 x 1200mm

Plywood Weight
24kg
Moisture Resistant MDF Weight
26kg

Perform panel can also be cut to specific sizes to suit the customers’ requirements. Please get in touch if you wish to enquire about a custom size.

Tolerances

  • Length +/ 1.5mm
  • Width +/- 0.5mm
  • Thickness +/- 0.5mm
  • Difference from level +/- 0.2mm
  • Curving Convex - 1.00mm
  • Curving Concave - 2mm
